Part No. |
Cable Spec.(mm²) |
Dimension(mm) | ||
|---|---|---|---|---|
| D | d | L | ||
| SC-DIN-25 | 25 | 7 | 10 | 50 |
| SC-DIN-35 | 35 | 8.2 | 12.5 | 55 |
| SC-DIN-50 | 50 | 10 | 14.5 | 65 |
| SC-DIN-70 | 70 | 11.5 | 16.5 | 68 |
| SC-DIN-95 | 95 | 13.5 | 19 | 78 |
| SC-DIN-120 | 120 | 15.5 | 21 | 86 |
| SC-DIN-150 | 150 | 17 | 23.5 | 94 |
| SC-DIN-185 | 185 | 19 | 25.5 | 98 |
| SC-DIN-240 | 240 | 21.5 | 29 | 108 |
| SC-DIN-300 | 300 | 24.5 | 32 | 119 |
| SC-DIN-400 | 400 | 27.5 | 38.5 | 140 |
| SC-DIN-500 | 500 | 31 | 42 | 150 |
| SC-DIN-630 | 630 | 34.5 | 44 | 160 |
