Codice ordinazione ■ Order code ■ Code article ■ Bestell-Nummer ■ Código pedido
- POLI LT 10 mm 109.100.310
- POLI LT 13 mm 109.130.310
- POLI LT 16 mm 109.160.310
- POLI LT 19 mm 109.190.310
Codice ordinazione ■ Order code ■ Code article ■ Bestell-Nummer ■ Código pedido
| Technical Data | |
|---|---|
| Package type | Flat - round (min. diam.700mm - 28”) Opt: round package base kit ø 500mm |
| Strap quality | PP/PET |
| Strap width | 10 mm - 19 mm |
| Strap thickness | 0.4 mm - 0.9 mm |
| Max. tension | 2.500N (variable with friction). |
| Max. tension speed | Around 11 m/min. |
| Joint type | Friction weld seal |
| Weight | around 4.9 Kg |
| Air pressure | 6 - 7 bar max |
| Air consumption | 12 l/s |
Codice ordinazione ■ Order code ■ Code article ■ Bestell-Nummer ■ Código pedido
| Technical Data | |
|---|---|
| Package type | Flat - round |
| Strap quality | PET/PP |
| Strap width | 10 mm - 19 mm |
| Strap thickness | 0.6 mm - 1.30 mm (opt. 1.5mm) |
| Max. tension | - |
| Max. tension speed | - |
| Joint type | Friction weld seal |
| Weight | around 2.3 Kg |
| Air pressure | 6 - 7 bar max |
| Air consumption | 12 l/s |
