Description:
- Wide application range.
- Compact design,requires little installation space.
- Can be used with almost every type of conductor and material.
- Torque-controlled shear-head bolts guarantee a good electrical contact.
- Easy installation with standard socket spanner.
Characteristics:
- Total cross-section: 25-400 mm
- Pr-engineered design for perfect fit in medium voltage cable accessories up to 42 kV
- Lugs are suitable for out door and indoor applications.
- Connector and lug bodies are made of a high-tensile,tinplate aluminium alloy.
- Use in cable accessories.
Technical Data
| Cable Size(mm²) |
Size Of Bolt |
Code |
Dimension |
Bolt Quantity |
| B |
I |
AF |
| 25-95 |
M16 |
AMO25/95-16 |
34 |
80 |
13 |
1 |
| 95-240 |
M16 |
AMO95/240-16 |
34 |
120 |
19 |
2 |
| 185-300 |
M16 |
AMO185/300-16 |
34 |
115 |
22 |
2 |
| 240-400 |
M16 |
AMO240/400-16 |
34 |
115 |
24 |
3 |
