Model |
Dimension(mm) | |||||
|---|---|---|---|---|---|---|
| Dia | D | d | L | W | S | |
| DT-10 | 8.4 | 9 | 5.5 | 66 | 16 | 2.2 |
| DT-16 | 8.4 | 10 | 6 | 67 | 16 | 2.5 |
| DT-25 | 8.4 | 11 | 7 | 70 | 18 | 3 |
| DT-35 | 10.5 | 12 | 8.5 | 79 | 20 | 3 |
| DT-50 | 10.5 | 14 | 9.6 | 87 | 23 | 3.5 |
| DT-70 | 12.5 | 16 | 12 | 95 | 26 | 4 |
| DT-95 | 12.5 | 18 | 13 | 105 | 28 | 4.5 |
| DT-120 | 14.5 | 20 | 15 | 112 | 30 | 5 |
| DT-150 | 14.5 | 22 | 16 | 118 | 34 | 5.5 |
| DT-185 | 16.5 | 25 | 18 | 125 | 38 | 6 |
| DT-240 | 16.5 | 27 | 20 | 136 | 42 | 7 |
| DT-300 | 21 | 30 | 23 | 160 | 48 | 8 |
| DT-400 | 21 | 34 | 26 | 165 | 54 | 9 |
| DT-500 | 21 | 38 | 29 | 190 | 64 | 9.5 |
