Item No. |
Dimension(mm) | |||||
|---|---|---|---|---|---|---|
| ΦE | ΦD | Φd | ΦW | ΦB | L | |
| 8#10 | 5.1 | 7.1 | 4.8 | 11.8 | 13 | 33.3 |
| 8*1/4 | 6.8 | 7.1 | 4.8 | 11.8 | 13 | 33.3 |
| 8*5/16 | 8.3 | 7.1 | 4.8 | 11.8 | 13 | 33.3 |
| 8*3/8 | 10.4 | 7.1 | 4.8 | 14.5 | 13 | 33.3 |
| 8*1/2 | 13.1 | 7.1 | 4.8 | 17 | 13 | 33.3 |
| 6#10 | 5.1 | 8.1 | 5.9 | 11.8 | 15 | 37.3 |
| 6*1/4 | 6.8 | 8.1 | 5.9 | 13.7 | 15 | 37.3 |
| 6*5/16 | 8.3 | 8.1 | 5.9 | 13.7 | 15 | 37.3 |
| 6*3/8 | 10.4 | 8.1 | 5.9 | 13.7 | 15 | 37.3 |
| 6*1/2 | 13.1 | 8.1 | 5.9 | 17 | 14 | 37.3 |
| 4*1/4 | 6.8 | 9.5 | 7.3 | 13.8 | 15.5 | 38.9 |
| 4*5/16 | 8.3 | 9.5 | 7.3 | 13.8 | 15.5 | 38.9 |
| 4*3/8 | 10.4 | 9.5 | 7.3 | 14.5 | 15.5 | 38.9 |
| 4*1/2 | 13.1 | 9.5 | 7.3 | 17 | 15 | 38.9 |
| 2*1/4 | 6.8 | 11.1 | 8.5 | 16.5 | 16 | 41.1 |
| 2*5/16 | 8.3 | 11.1 | 8.5 | 16.5 | 16 | 41.1 |
| 2*3/8 | 10.4 | 11.1 | 8.5 | 16.5 | 16 | 41.1 |
| 1*1/4 | 6.8 | 11.7 | 9.1 | 16.4 | 16 | 43.6 |
| 1*5/16 | 8.3 | 11.7 | 9.1 | 16.4 | 16 | 43.6 |
| 1*3/8 | 10.4 | 11.7 | 9.1 | 17.1 | 16 | 43.6 |
| 1*1/2 | 13.1 | 11.7 | 9.1 | 19.1 | 16 | 43.6 |
| 1/0 1/4 | 6.8 | 13 | 10.4 | 18.4 | 19 | 46.8 |
| 1/0 5/16 | 8.3 | 13 | 10.4 | 18.4 | 19 | 46.8 |
| 1/0 3/8 | 10.4 | 13 | 10.4 | 18.4 | 19 | 46.8 |
| 1/0 1/2 | 13.1 | 13 | 10.4 | 21 | 19 | 46.8 |
| 2/0 1/4 | 6.8 | 14.2 | 11.7 | 21 | 22 | 52.4 |
| 2/0 5/16 | 8.3 | 14.2 | 11.7 | 21 | 22 | 52.4 |
| 2/0 3/8 | 10.4 | 14.2 | 11.7 | 21 | 22 | 52.4 |
| 2/0 1/2 | 13.1 | 14.2 | 11.7 | 21 | 21 | 52.4 |
| 3/0 5/16 | 8.3 | 15.7 | 13 | 23.1 | 22.5 | 55.9 |
| 3/0 3/8 | 10.4 | 15.7 | 13 | 23.1 | 22.5 | 55.9 |
| 3/0 1/2 | 13.1 | 15.7 | 13 | 23.1 | 22.5 | 55.9 |
| 4/0 5/16 | 8.3 | 17.2 | 14.2 | 25.8 | 24 | 60.5 |
| 4/0 3/8 | 10.4 | 17.2 | 14.2 | 25.8 | 24 | 60.5 |
| 4/0 1/2 | 13.1 | 17.2 | 14.2 | 25.8 | 24 | 60.5 |
